ATESS PCS250 Station
PCS250 Station
Outdoor containerized solution with IP54 protection level to handle harsh environment condition
Features:
- Cost effective
- plug and play
- Highy integrated
- Easy installation and maintenance
Datasheet:
|
|
PCS250 Station |
|
AC (on-grid) |
|
|
Apparent Power |
275kVA |
|
Rated Power |
250kW |
|
Rated Voltage |
400V |
|
Rated Current |
361A |
|
Grid Voltage Current |
310-450V |
|
Rated Frequency |
50/60Hz |
|
Frequency Range |
45-55/55-65Hz |
|
Isolation Method |
Transformer |
|
Overload Capability |
110%-10 mins 120%-1min |
|
AC Connection |
3/N/PE |
|
DC (Battery) |
|
|
Cell Type |
3.2V/100Ah |
|
Configuration of Battery Module |
12S2P |
|
Configuration of battery bank |
18S2P |
|
Battery Capacity |
276 kWh |
|
Rated Voltage |
691.2V |
|
Battery Voltage Range |
604.8V-766.8V |
|
Rated Current |
417A |
|
Rated charge/Discharge |
0.5C |
|
Max.charge/discharge |
1C |
|
Communication |
CAN |
|
DC (PV) |
|
|
Max. PV open circuit voltage |
1000V Dc |
|
Recommended PV Power |
250kWp |
|
MPPT Voltage Range |
350-850V |
|
Full Load MPPT voltage Range |
480-850V |
|
Max. input current |
575A(115A*5) |
|
Number of MPPT |
5 |
|
General Information |
|
|
Configuration |
PCS250+PBD250+Bypass250+BR138*2 |
|
Dimensions |
6058/2591/2438mm |
|
Weight |
10000kg |
|
Operating Temperature |
-25°C-+55°C |
|
Relative Humidity |
0-95% non-condensing |
|
Protection Degree |
IP54 |
|
Maximum Altitude |
6000m (derate over 3000m) |
|
Standby consumption |
<100W |
|
Lightning system |
LED Lighting |
|
Fire fighting system |
Industrial Grade |
|
Cooling of battery chamber |
HVAC |
|
Cooling of PCS chamber |
Forced-air |
|
Transfer between on/off grif |
Automatic≤10ms |
