ATESS RTF300 Bidirectional Battery Inverter

ATESS
SKU:
RTF300
Availability:
4-6 weeks

Contact us for pricing

Log in for pricing

Weight:
250.00 KGS
Width:
125.00 (cm)
Height:
201.00 (cm)
Depth:
90.00 (cm)
Current Stock:

Download Datasheet

DOWNLOAD DATASHEET

Bidirectional battery inverter from 300kW to 600kW, can be used alone or with solar charge controllers and other accessories for different application scenarios.

Features:

  • AC-DC converter
  • Flexible configuration
  • Touchscreen LCD
  • Paralleling multiple units
  • Support remote control of DG

Datasheet:



RTF300

AC(on-grid)

Rated power

280kW

Rated voltage

400V

Rated current

404A

Voltage range

260V-450V

Rated Frequency

50±10%

PF

≥0.98

THDI

≤5%

Efficiency

≥95%

DC(output)

Voltage range

200Vdc-950Vdc (full above 500V derate below 500V)

Max output current

560A

Output current ripple

≤1%

Voltage accuracy

≤0.5%

Current accuracy

≤1%

General Information

Nosie emission

≤68Db(A)@1m

Operating Temperature

-40 °C~+45 °C, full load; 45 °C~55 °C, half load

Storage temperature

-40 °C~85 °C

Relative Humidity

0~95% non-condensing

Maximum altitude

< 2000m

Cooling

Smart air cooling

Dimension (W/H/D)

1204/1958/853mm

Weight

245kg

Communication

Display

Touch screen

Communication

RS485/CAN
