Staubli Male cable coupler
The original MC4-Evo 2
- Invented by Stäubli engineers in Switzerland
- Manufactured in compliance with European Conformity
- MC4 is a protected trademark of Stäubli
- Guarantees high performance even in harsh environment. Further it combines best-in-class features for DC PV connectors such as:
- V 1500 DC certified (TUV / UL / JET)
- Maximum current rating 69A
- Salt mist spray test & ammonia resistant
|
Technical Data
|
|
Connector system
|
MC4-Evo 2
|
|
Ambient Temperature Range
|
-40°C…+85°C(TUV/UL)
|
|
Upper Limiting Temperature
|
115°C
|
|
Degree of protection
|
IP68 (1m,1h)/IP65
|
|
Degree of Protection, unmated
|
IP2X
|
|
Category
|
CAT III
|
|
Degree of Pollution
|
3
|
|
Max. contact resistance of the connector
|
0.2mΩ
|
|
Rated Impulse Voltage
|
16kV
|
|
Contact System
|
MULTILAM
|
|
Type of Connection
|
Crimping
|
|
Contact Material
|
Copper, tin plated
|
|
Insulation Material
|
PA
|
|
Locking System
|
Locking Type
|
|
Fire Protection Class
|
UL94:V-0
|
|
Ammonia Resistance (acc. To TUV)
|
Yes
|
|
Salt Mist spray test, degree of severity 6
|
yes
|
|
TUV Rheiland certifications number
|
R 60127169
|
|
UL-File number
|
E343181
|
|
JET Number of certification
|
B18T0049
|
